DeWalt XR Li-Ion DCD771 - Technical Data; Definitions: Safety Guidelines

26
ENGLISH
a
WARNING: To reduce the risk of injury, read the
instructionmanual.
Definitions: Safety Guidelines
The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to
thesesymbols.

DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
seriousinjury.
EC‑Declaration of Conformity
Machinery Directive
Drill/Driver/Hammerdrill
DCD771, DCD776
DeWALT
declares that these products described under
Technical Data are in compliance with:
2006/42/EC, EN60745‑1:2009+A11:2010, EN60745‑2‑1:2010.
These products also comply with Directive 2014/30/EU and
2011/65/EU. For more information, please contact
DeWALT
at
the following address or refer to the back of themanual.
The undersigned is responsible for compilation of the technical
file and makes this declaration on behalf of
DeWALT
.
Markus Rompel
Vice‑President Engineering, PTE‑Europe
DeWALT
, Richard‑Klinger‑Straße 11,
65510, Idstein, Germany
31.05.2017

WARNING: The declared vibration and/or noise emission
level represents the main applications of the tool. However
if the tool is used for different applications, with different
accessories or poorly maintained, the vibration and/or
noise emission may differ. This may significantly increase
the exposure level over the total workingperiod.
An estimation of the level of exposure to vibration and/or
noise should also take into account the times when the tool
is switched off or when it is running but not actually doing
the job. This may significantly reduce the exposure level
over the total workingperiod.
Identify additional safety measures to protect the operator
from the effects of vibration and/or noise such as: maintain
the tool and the accessories, keep the hands warm (relevant
for vibration), organisation of workpatterns.
The vibration and/or noise emission level given in this information
sheet has been measured in accordance with a standardised test
given in EN60745 and may be used to compare one tool with
another. It may be used for a preliminary assessment ofexposure.
DCD771 DCD776
Voltage V
DC
18 18
Type 1/10/20 1/10/20
Battery Type Li-Ion Li-Ion
Power output W 300 300
No-load speed
1st gear min
-1
0–450 0–450
2nd gear min
-1
0–1500 0–1500
Impact rate
1st gear min
-1
– 0–7650
2nd gear min
-1
– 0–25500
Max. torque (hard/soft) Nm 42/24 42/24
Chuck capacity mm 1.5–13 1.5–13
Maximum drilling capacity
Wood mm 30 30
Metal mm 13 13
Masonry
mm – 13
Weight (without battery pack) kg 1.28 1.34
Noise values and/or vibration values (triax vector sum) according to
EN60745-2-1.
L
PA
(emission sound pressure level) dB(A) 72 85
L
WA
(sound power level) dB(A) 80 96
K (uncertainty for the given sound
level)
dB(A) 3 3
Drilling into metal
Vibration emission value a
h,D
= m/s
2
< 2.5 < 2.5
Uncertainty K = m/s
2
1.5 1.5
Screwdriving
Vibration emission value a
h,D
= m/s
2
< 2.5 < 2.5
Uncertainty K = m/s
2
1.5 1.5
Drilling into concrete
Vibration emission value a
h,ID
= m/s
2
– 14.0
Uncertainty K = m/s
2
– 2.4
Congratulations!
You have chosen a
DeWALT
tool. Years of experience, thorough
product development and innovation make
DeWALT
one of the
most reliable partners for professional power toolusers.
Technical Data
English (original instructions)
CORDLESS COMPACT 13 mm DRILL/DRIVER/HAMMERDRILL
DCD771, DCD776
