DeWalt XR LI-ION DCS334P2 Original Instructions

28
ENGLISH
WARNING: To reduce the risk of injury, read the
instructionmanual.
Definitions: Safety Guidelines
The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to
thesesymbols.

DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
seriousinjury.

WARNING: Indicates a potentially hazardous situation
which, if not avoided, could result in death or
seriousinjury.

CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderateinjury.
NOTICE: Indicates a practice not related to
personal injury which, if not avoided, may result in
propertydamage.

Denotes risk of electricshock.

Denotes risk offire.
EC-Declaration of Conformity
Machinery Directive
Jigsaw
DCS334, DCS335
DeWALT declares that these products described under
Technical Data are in compliance with:
2006/42/EC, EN62841-1:2015, EN62841-2-11: 2016.
These products also comply with Directive 2014/30/EU and
2011/65/EU. For more information, please contact DeWALT at
the following address or refer to the back of themanual.
The undersigned is responsible for compilation of the technical
file and makes this declaration on behalf ofDeWALT.
Markus Rompel
Vice-President Engineering, PTE-Europe
DeWALT, Richard-Klinger-Straße 11,
D-65510, Idstein, Germany
25.02.2020
Identify additional safety measures to protect the operator
from the effects of vibration and/or noise such as: maintain
the tool and the accessories, keep the hands warm (relevant
for vibration), organisation of workpatterns.
The vibration and/or noise emission level given in this
information sheet has been measured in accordance with
a standardised test given in EN62841and may be used to
compare one tool with another. It may be used for a preliminary
assessment ofexposure.

WARNING: The declared vibration and/or noise emission
level represents the main applications of the tool. However
if the tool is used for different applications, with different
accessories or poorly maintained, the vibration and/or
noise emission may differ. This may significantly increase
the exposure level over the total workingperiod.
An estimation of the level of exposure to vibration and/or
noise should also take into account the times when the tool
is switched off or when it is running but not actually doing
the job. This may significantly reduce the exposure level
over the total workingperiod.
DCS334 DCS335
Voltage V
DC
18 18
Type 1 1
Battery type Li-Ion Li-Ion
No-load speed min
-1
0–3200 1000–3200
Stroke length mm 26 26
Cutting depth in:
wood mm 135 135
aluminum mm 25 25
steel mm 10 10
Bevel angle adjustment (l/r) ˚ 0–45 0–45
Weight (without battery pack) kg 2.1 2.0
Noise values and vibration values (triax vector sum) according to EN62841-2-11:
L
PA
(emission sound pressure level) dB(A) 85 85
L
WA
(sound power level) dB(A) 96 96
K (uncertainty for the given sound
level)
dB(A) 3 4
While cutting board
Vibration emission value a
h,B
= m/s
2
5.2 7.7
Uncertainty K = m/s
2
1.5 1.5
While cutting sheet metal
Vibration emission value a
h,M
= m/s
2
4.9 7.7
Uncertainty K = m/s
2
1.6 3.1
Congratulations!
You have chosen a DeWALT tool. Years of experience, thorough
product development and innovation make DeWALT one of the
most reliable partners for professional power toolusers.
Technical Data
English (original instructions)
CORDLESS JIGSAW
DCS334, DCS335
