DeWalt XR LI-ION DCS334P2 Original Instructions

36
ENGLISH
Lock-Off Button and Variable Speed Trigger
(Fig.A)
DCS334
To lock the variable speed trigger
1
, press the lock-off
button
2
. When the lock-off button is depressed to the lock
Proper Hand Position (Fig.L)

WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position as shown.

WARNING: To reduce the risk of serious personal injury,
ALWAYS hold securely in anticipation of a sudden
reaction.
Proper hand position requires one hand on the main
handle
9
.

WARNING: Always wear proper personal hearing
protection. Under some conditions and duration of use,
noise from this product may contribute to hearingloss.

WARNING:
• Make sure your workpiece is well secured. Remove
nails, screws and other fasteners that may damage
theblade.
• Check that there is sufficient space for the blade
underneath the workpiece. Do not cut materials that
are thicker than the maximum cuttingdepth.
• Use sharp saw blades only. Damaged or bent saw
blades must be removedimmediately.
• Never run your tool without a sawblade.
• For optimal results, move the tool smoothly and
constantly over the workpiece. Do not exert lateral
pressure on the saw blade. Keep the shoe flat on the
workpiece. When sawing curves, circles or other round
shapes, push the tool gentlyforward.
• Wait until the tool has come to a standstill before
removing the saw blade from the workpiece. After
sawing the blade may be very hot. Do nottouch.
OPERATION
Instructions for Use

WARNING: Always observe the safety instructions and
applicableregulations.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
DCS335
The speed control dial
3
can be used for advance setting of the
required range ofspeed.
1. Turn the electronic control dial to the required level. The
DCS335 will turn on at that speed when the on/off switch is
moved to the ON position. The required setting depends on
the thickness and kind ofmaterial.
NOTE: Use high speeds for sawing soft materials such aswood.
Setting the Electronic Sawing Speed
(Fig.A,K)
DCS334
To preset the sawing speed, turn the speed control dial
3
to the
desired level. The higher the number on the speed control dial,
the higher the sawing speed. The sawing speed varies with the
pressure exerted on the variable speed trigger
1
, but will not
exceed the speed that is set by the speed control dial
3
. The
required setting depends on the thickness and kind ofmaterial.
NOTE: Use high speeds for sawing soft materials such aswood.
Anti-Splinter Insert (Fig.I, J)
NOTE: Do not use the anti-splinter insert with the flush
cuttingbladeDT74.
The anti-splinter insert
20
should be used when trying to
minimize tear-out, especially when cutting veneer, laminate, or
finished surfaces, such as paint. The anti-splinter insert should
be installed into the anti-scratch shoe cover
18
. If the no-mar
cover is not used, install anti-splinter insert into shoe
7
.
Removeable Anti-Scratch Shoe Cover (Fig.I)
The anti-scratch shoe cover
18
should be used when cutting
surfaces that scratch easily, such as laminate, veneer orpaint.
To attach anti-scratch shoe cover
18
, place the front of the
shoe
7
into the front of the anti-scratch shoe cover and lower
the jig saw. The anti-scratch shoe cover will click securely onto
the rear of theshoe.
To remove anti-scratch shoe cover, grasp the anti-scratch shoe
cover from the bottom; holding onto the two rear tabs
21
remove the anti-scratch shoecover.
Dust Extraction (Fig.A, H)

WARNING: Dust can be hazardous to health. Always
work with a dust extractor. Always observe the national
regulations for work with dust emittingtools.
The dust extraction chute in combination with the dust
extraction shroud helps extract dust from the workpiece surface,
when connected to a suitable dust extractionsystem.
NOTE: The tool will not bevel if the dust extraction accessories
are attached to thetool.
1. Place the dust extraction shroud
15
onto the finger
guard
5
(Fig. A) until it clicks intoplace.
2. Slide the dust chute17 from the back of the tool until
it snaps into the dust shroud. Be sure the adapter end is
facingup.
3. To connect a vacuum to the dust chute
17
, place a DeWALT
AirLock (DWV9000), found on all full size DeWALT vacuum
hoses, over the dust collection port, and twist the collar
to lock it into place. The dust chute will also fit a standard
35mmconnector.
Dust Blower (Fig.G)
The dust blower
19
helps clear the cutting area of debris
created from theblade.
