35
ENGLISH
7
Front handle
8
Guard
9
Arbor screw
10
Spindle lock button
11
Guard rotation lever
12
Shoe
13
Water valve
14
Date code
15
Water inlet
Intended Use
Your cut-off tool is designed for professional cutting
applications. Only use wet cut method when cutting concrete.
Dry cutting is possible when cuttingmetal.
DO NOT use in the presence of flammable liquids orgases.
Your cut-off tool is a professional powertool.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
withoutsupervision.
This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
DO NOT cut concrete without connecting the water
supplysystem.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. Make sure the
trigger switch is in the OFFposition. An accidental start-up
can causeinjury.
WARNING: Use only
DeWALT
battery packs andchargers.
Inserting and Removing the Battery Pack
from the Tool (Fig. B)
WARNING: Do not work with unlatched battery door.
Prevent water entering into the batterycompartment.
NOTE: Make sure your battery pack
24
is fullycharged.
To Install the Battery Pack into the Tool
1. Unlatch and open the battery door
4
.
2. To install the battery pack
24
into the tool, align the
battery pack with the rails inside the tool and slide it in
until the battery pack is firmly seated. Ensure that it does
notdisengage.
3. Close the battery door and ensure it is closedsecurely.
To Remove the Battery Pack from the Tool
1. Unlatch and open the batterydoor.
2. Press the release button
16
and firmly pull the battery pack
out of thetool.
3. Insert it into the charger as described in Charging aBattery.
Do not leave the battery dooropen.
Fuel Gauge Battery Packs (Fig. B)
Some
DeWALT
battery packs include a fuel gauge which
consists of three green LED lights that indicate the level of
charge remaining in the batterypack.
To actuate the fuel gauge, press and hold the fuel gauge
button
23
. A combination of the three green LED lights will
illuminate designating the level of charge left. When the level
of charge in the battery is below the usable limit, the fuel gauge
will not illuminate and the battery will need to berecharged.
NOTE: The fuel gauge is only an indication of the charge left on
the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature
and end-userapplication.
Installing Wheels (Fig. A, C)
WARNING: Burn Hazard. Sharp parts. ALWAYS wear
gloves when changing wheels. Wheels have sharp edges
or may get extremely hot during operation, and may
damage barehands.
1. Lay unit on a firm surface, with the spindle
21
facingupward.
2. Hold spindle lock button
10
to keep the spindle
fromturning.
3. Using supplied 12.7mm wrench
5
(located in the battery
compartment), remove spindle nut
17
, outer clamp
washer
18
and used wheel
19
if one is installed. Spindle
threads are righthand.
4. The inner clamp washer
20
is held in place with a double D
shaft and retainingring.
5. Slip wheel over spindle. Be sure wheel goes over pilot
diameter of inner clamp washer. Slip on outer clamp
washer. Start threading on spindle nut which will self align
outer clampwasher. Make sure the wheel is fitted in the
correctorientation.
6. Engage spindle lock button and tighten nut with wrench.
Do not over tighten spindlenut.
7. Turn wheel by hand to ensure it is properly centered. The
wheel should not hit the shoe, guard or nut. The nut and
flanges should betight.
CAUTION: Only use 230mm Type 1/41 wheels with
22.2mm arbor hole with this tool. Never force a wheel
onto the machine or alter the size of the arborhole.
Adjusting the Guard Angle (Fig. D)
WARNING: There is a higher risk of kickback when guard
is moved backwards leading to wider opening. The guard
must be opened wider only whenrequired.
You can adjust the angle of theguard.
1. To adjust the angle of the guard, pull back the guard
rotation lever
11
and holdit.
2. Grasp the guard
8
firmly and rotate to desiredangle.
3. Release the guard rotation lever and make sure it engages,
locking the guard in place. If the guard rotation lever doesn't
engage, rotate the guard slightly until the guard rotation
lever returns to the lockedposition.
