NDS3306I 6 in 1 ISDB-T Modulator User Manual
15
When users click “Channel config” button, it triggers a dialog box as follow where users can
set the corresponding channel configration.
Parameters → IP Stream:
NDS3306I supports TS to output in IP (6*MPTS) format through the DATA port.
Clicking ‘IP Stream’, it will display the interface as Figure-13 where to set IP out
parameters.
Figure-13
When users click “Quickly Config” button, it triggers a dialog box where users can set all
channels MPTS configration simultaneously.
Quickly Config
Channel Config
Click the box to enable the status
