54
RMC Replacement and Adjustment
The 3 main components are the Sensing strip mounted in the tumbler. The rotating sensor
mounted on the trunnion, and the stationary sensor sending and receiving the signals from the
sensing strip.
9558-034-001
Sensing Strip, Moisture
9857-248-001
Rotating PCB, RMC
9857-247-001
Stationary PCB, RMC
Part # 8533-112-001 7/21
