8514-219-001 REV E PAGE 24
13) If you pressed the STOP touch pad switch on the dryer controller to escape the
programming mode, you may now start the dry cycle by pressing the START touch pad
switch on the dryer controller.
PERMANENT DRYER CONTROLLER PROGRAMMING EXAMPLE
REQUIREMENTS: Dry a load with 50 minutes of actual heat at 195
0
F and three minutes of
cool down.
The following procedure will show you how to permanently modify the existing dry cycle 1
program for one cycle of drying. It is based on the assumption that the factory defaults have
not been permanently changed. If they have been changed, the steps of this procedure will
be the same, but the values that are displayed will be different. The amount of times that the
UP or DOWN touch pad switch on the dryer controller must be pressed and released may also
be different.
If you want the change to be temporary (for only one dry cycle), go to the “TEMPORARY
DRYER CONTROLLER PROGRAMMING” section of this manual.
PROCEDURE
1) After the load has been placed in the dryer, press and release the UP or DOWN touch pad
switch on the dryer controller until the L.E.D. for dry cycle 1 is illuminated.
2) Press and release the PROG touch pad switch on the dryer controller. The dryer controller
display will not change.
3) Immediately, press and release the UP touch pad switch on the dryer controller. The
controller display will change from “LOAd” to “Prog”. You have now entered the
permanent programming mode. The dry time L.E.D. will remain on and the programming
L.E.D. will illuminate.
4) Press and release the SELECT/ENTER touch pad switch on the dryer controller once. The
dry time L.E.D. and programming L.E.D. will remain on, the dry time L.E.D. will illuminate,
and the dryer controller will show the number “35”.
5) Press the UP touch pad switch on the dryer controller 18 times until the dryer controller
display shows the number “53”.
6) Press and release the SELECT/ENTER touch pad switch on the dryer controller once. The
dry time L.E.D. and programming L.E.D. will remain on, the dry time L.E.D. will switch off,
the temperature L.E.D. will illuminate, and the dryer controller display will show the
number “180”.
7) Press and release the UP touch pad switch on the dryer controller three times until the
dryer controller display shows the number “195”.
8) Press and release the SELECT/ENTER touch pad switch on the dryer controller. The dry
time L.E.D. and the programming L.E.D. will remain on, the temperature L.E.D. will switch
off, the cool down L.E.D. will illuminate, and the dryer controller display will show the
number “5”.
