ADJUSTMENT REQUIRED PER COUNTRY
Gas Category Country of Destination
Supply Pressure
mbar (kPa)
Regulator Setting Pressure
mbar (kPa) Designation
I2H(20) BG, LV, IS 20 (2) 8.7 (0.87) G20
I2H(25) HU 25 (2.5) 8.7 (0.87) G20
I2E LU 20 (2) 8.7 (0.87) G20
I3B/P(30) IS, BE, FR, NL 30 (3) 22.4 (2.24) G30
I3P(30) NL 30 (3) 22.4 (2.24) G31
I3P(37) BE, FR, NL 37 (3.7) 22.4 (2.24) G31
I3P(50) NL 50 (5) 22.4 (2.24) G31
II2H3B/P(30) CY, DK, EE, FI, HR, IT, LT, NO, RO, SE, SI, SK, TR 20 (2) / 30 (3) 8.7 (0.87) / 22.4 (2.24) G20 / G30
II2H3B/P(50) AT, CH, SK 20 (2) / 50 (5) 8.7 (0.87) / 22.4 (2.24) G20 / G30
II2H3P(37) CH, CZ, ES, GB, GR, HR, IE, IT, LT, PT, SI, SK 20 (2) / 37 (3.7) 8.7 (0.87) / 22.4 (2.24) G20 / G31
II2L(20)3B/P(30) RO 20 (2) / 30 (3) 12.2 (1.22) / 22.4 (2.24) G25 / G30
II2E3B/P(30) RO 20 (2) / 30 (3) 8.7 (0.87) / 22.4 (2.24) G20 / G30
II2E3B/P(37) PL 20 (2) / 37 (3.7) 8.7 (0.87) / 22.4 (2.24) G20 / G30
II2E3B/P(50) DE 20 (2) / 50 (5) 8.7 (0.87) / 22.4 (2.24) G20 / G30
Table 7-4 Gas Adjustments Required Per Country
The inlet gas connection to the unit is ISO 7-RC 3/4 thread. The connection to the appliance shall
be made with a flexible hose suitable for the appliance category in accordance with national
installation regulations. The size of the piping to supply the dryer should be determined by
reference to the national installation practice and consultation with the local gas supplier.
INFORMATION
An individual gas shutoff valve is required
for each dryer and must comply with EN
331
A joint compound resistant to the action of liquefied petroleum gases should be employed in
making pipe connections.
All pipe connections should be checked for leakage with soap solution. Never check with an
open flame.
A drip tee should be provided in the gas piping entering the unit to catch dirt and other foreign
articles.
