Dexter Laundry C-Series - Specifications

8514-234-001 REV N page 3
SPECIFICATIONS
30 lb. Commercial Dryer: T-30
DC0030N_-(10/11/15)EC_X (60 Hz), DC0030N_-39AC_X (50 Hz)
Cabinet Height 72 1/4” 1835 mm.
(Assumes minimum leveling leg adjustment)
Cabinet Width 31 1/2” 800 mm.
Cabinet Depth 41 3/4” 1058 mm.
Floor to Bottom of Door 28 3/4” 730 mm.
Door Opening 22 5/8” 575 mm.
Dry Wt. Capacity 30 lbs. 13.6 kg.
Cylinder Diameter 30” 762 mm.
Cylinder Depth 27 1/2” 699 mm.
Cylinder Volume 11.25 cu. ft. 319 liters
Lint Screen Area 515 sq. in. 3323 sq. cm.
Gas Input (60 hz) 90,000 Btu/hr 95MJ/hr (26.4 kW)
Gas Input (50 hz) 74,000 Btu/hr 78MJ/hr (21.7 kW)
Gas Supply Connection 1/2” 12.7 mm.
Natural Gas Supply (Water Column) 5” - 8” 127 mm. - 203 mm./1.25kPa – 1.99kPa
Natural Burner Manifold
(60 hz Water Column) 3.5” 88.9 mm./0.87kPa
(50 hz Water Column) 3.4” 86.4 mm./0.84kPa
Propane or ULPG Supply (Water Column) 11.5” – 13.5” 292 mm. - 343 mm./2.86kPa - 3.36kPa
Burner Manifold Pressure
Propane (60 hz Water Column) 11” 279 mm./2.75kPa
Propane or ULPG (50 hz Water Column) 10” 254 mm./2.50kPa
Exhaust Size 8” 203 mm.
Make-up Air 1.0 sq. ft. 929 sq. cm.
Example: 1.0 sq. ft = 1 ft. long X 1 ft. wide
Motor Size 1/2 H.P. .373 kW
Airflow (60 hz) 830 CFM 23.5 m^3/min
Airflow (50 hz) 690 CFM 19.5 m^3/min
Electrical Specifications - 120/60/1
Voltage/Hz/Phase 120V/60Hz/1Phase
Running Amps 9.6
Circuit Protection Amps 15
Wire Size 12 gauge
Electrical Service 2 wire + ground
Electrical Specifications – 208-240/60/1
Voltage/Hz/Phase 208-240V/60Hz/1Phase
Running Amps 5.1
Circuit Protection Amps 10
Wire Size 14 gauge
Electrical Service 2 wire + ground
Electrical Specifications - 220-240/50/1
Voltage/Hz/Phase 220-240V/50Hz/1Phase
Running Amps 5.1
Circuit Protection Amps 10
Wire Size 14 gauge
Electrical Service 2 wire + ground
Shipping Weight 507 lbs. 231 kg.
Net Weight 463 lbs. 210 kg.
Clearance Behind Machines (min.) 18” 457 mm.
