Dexter Laundry C-Series - Page 4

8514-234-001 REV N page 4
SPECIFICATIONS
50 lb. Commercial Dryer: T-50
DC0050N_-(10/11/15)EC_X (60 Hz), DC0050N_-39AC_X (50 Hz)
Cabinet Height 72 1/4” 1835 mm.
(Assumes minimum leveling leg adjustment)
Cabinet Width 34 1/2” 875 mm.
Cabinet Depth 48” 1218 mm.
Floor to Bottom of Door 27 1/4” 691 mm.
Door Opening 25 5/8” 653 mm.
Dry Wt. Capacity 50 lbs. 24.9 kg.
Cylinder Diameter 32 1/2” 826 mm.
Cylinder Depth 33” 845 mm.
Cylinder Volume 15.84 cu. ft. 449.5 liters
Lint Screen Area 708 sq. in. 4568 sq. cm.
Gas Input (60 hz) 145,000 Btu/hr 153MJ/hr (42.5 kW)
Gas Input (50 hz) 120,000 Btu/hr 125MJ/hr (35.2 kW)
Gas Supply Connection 1/2” 12.7 mm.
Natural Gas Supply (Water Column) 5” - 8” 127 mm. - 203 mm./1.25kPa – 1.99kPa
Natural Burner Manifold
(60 hz Water Column) 3.5” 88.9 mm./0.87kPa
(50 hz Water Column) 3.5” 88.9 mm./0.87kPa
Propane or ULPG Supply (Water Column) 11.5” – 13.5” 292 mm. - 343 mm./2.86kPa - 3.36kPa
Burner Manifold Pressure
Propane (60 hz Water Column) 11” 279 mm./2.75kPa
Propane or ULPG (50 hz Water Column) 11” 279 mm./2.75kPa
Exhaust Size 8” 203 mm.
Make-up Air 1.25 sq. ft. 1161 sq. cm.
Example: 1.25 sq. ft = 1.25 ft. long X 1 ft. wide
Motor Size (60 Hz) 1 H.P. .746 kW
Motor Size (50 Hz) 3/4 H.P. .560 kW
Airflow (60 hz) 910 CFM 25.8 m^3/min
Airflow (50 hz) 760 CFM 21.5 m^3/min
Electrical Specifications - 120/60/1
Voltage/Hz/Phase 120V/60Hz/1Phase
Running Amps 9.6
Circuit Protection Amps 15
Wire Size 12 gauge
Electrical Service 2 wire + ground
Electrical Specifications – 208-240/60/1
Voltage/Hz/Phase 208-240V/60Hz/1Phase
Running Amps 5.1
Circuit Protection Amps 10
Wire Size 14 gauge
Electrical Service 2 wire + ground
Electrical Specifications - 220-240/50/1
Voltage/Hz/Phase 220-240V/50Hz/1Phase
Running Amps 5.1
Circuit Protection Amps 10
Wire Size 14 gauge
Electrical Service 2 wire + ground
Shipping Weight 611 lbs. 277 kg.
Net Weight 579 lbs. 263 kg.
Clearance Behind Machines (min.) 18” 457 mm.
