Dexter Laundry C-Series - Page 5

8514-234-001 REV N page 5
SPECIFICATIONS
80 lb. Commercial Dryer: T-80
DC0080N_-(10/11/15)EC_X (60 Hz), DC0080N_-39AC_X (50 Hz)
Cabinet Height 75 3/4” 1924 mm.
(Assumes minimum leveling leg adjustment)
Cabinet Width 38 1/2” 978 mm.
Cabinet Depth 51 3/4” 1313 mm.
Floor to Bottom of Door 29 1/4” 743 mm.
Door Opening 25 5/8” 653 mm.
Dry Wt. Capacity 80 lbs. 36.3 kg.
Cylinder Diameter 36 1/2” 927 mm.
Cylinder Depth 38” 965 mm.
Cylinder Volume 23.0 cu. ft. 651.3 liters
Lint Screen Area 823 sq. in. 5310 sq. cm.
Gas Input (60 hz) 215,000 Btu/hr 227MJ/hr (63.0 kW)
Gas Input (50 hz) 195,000 Btu/hr 204MJ/hr (57.1 kW)
Gas Supply Connection 3/4” 19.1 mm.
Natural Gas Supply (Water Column) 5” - 8” 127 mm. - 203 mm./1.25kPa – 1.99kPa
Natural Burner Manifold
(60 hz Water Column) 3.5” 88.9 mm./0.87kPa
(50 hz Water Column) 3.5” 88.9 mm./0.87kPa
Propane or ULPG Supply (Water Column) 11.5” – 13.5” 292 mm. - 343 mm./2.86kPa - 3.36kPa
Burner Manifold Pressure
Propane (60 hz Water Column) 11” 279 mm./2.75kPa
Propane or ULPG (50 hz Water Column) 11” 279 mm./2.75kPa
Exhaust Size 8” 203 mm.
Make-up Air 1.5 sq. ft. 1394 sq. cm.
Example: 1.5 sq. ft = 1.5 ft. long X 1 ft. wide
Motor Size (60 Hz) 1 H.P. .746 kW
Motor Size (50 Hz) 3/4 H.P. .560 kW
Airflow (60 hz) 1200 CFM 34.0 m^3/min
Airflow (50 hz) 1000 CFM 28.3 m^3/min
Electrical Specifications - 120/60/1
Voltage/Hz/Phase 120V/60Hz/1Phase
Running Amps 10.4
Circuit Protection Amps 15
Wire Size 12 gauge
Electrical Service 2 wire + ground
Electrical Specifications – 208-240/60/1
Voltage/Hz/Phase 208-240V/60Hz/1Phase
Running Amps 5.2
Circuit Protection Amps 10
Wire Size 14 gauge
Electrical Service 2 wire + ground
Electrical Specifications - 220-240/50/1
Voltage/Hz/Phase 220-240V/50Hz/1Phase
Running Amps 5.2
Circuit Protection Amps 10
Wire Size 14 gauge
Electrical Service 2 wire + ground
Shipping Weight 729 lbs. 331.2 kg.
Net Weight 699 lbs. 291.2 kg.
Clearance Behind Machines (min.) 18” 457 mm.
