8514-234-001 REV N page 37
Control Menu:
The Control menu allows for the user to observe important technical information for the control. No changes can
be made at this menu. See below for detailed information on each sub menu.
1. “Serial Number”: This is the control serial number.
2. “MAC Address”: The MAC Address is a unique identifier designated to the control by the manufacturer. It
allows the control to be recognized by network routers.
3. “IP Address”: The IP Address is the identifier given to the control by a network system.
4. “M Firmware”: The M Firmware is the Main Firmware currently loaded onto the control.
5. “C Firmware”: The C Firmware is the Communications Firmware currently loaded onto the control.
The figure below shows the sub menu options for Control:
