58
8514-311-001 REV PR
7.6 Dryer Fault Codes
FAULT #
FAULT
DESCRIPTION
ACTION
F1
Shorted thermostat
sensor.
Dryer stops and “F1” flashes on the 4-digit display. When short circuit on
sensor input is removed, “LOAd” appears on the 4-digit display and the
remaining dry time is reset.
F2
Open thermostat
sensor.
Dryer stops and “F2” flashes on the 4-digit display. When a good sensor is
connected to sensor input, “LOAd” appears on the 4-digit display and the
remaining dry time is reset.
F3
EEPROM corrupted.
Dryer will not start and “F3” appears on the 4-digit display. The power to the dryer
must be cycled to reset the controller. Fault should only occur when starting a dry
cycle.
F4
Gas valve on fault.
The drying temperature did not increase 1°F. in 5 minutes. “F4” will flash on the
display and the dry cycle will finish without calling for heat (energizing gas valve).
Opening the door or pressing the STOP touch pad switch will reset the fault and
clear the remaining time in the dry cycle.
F5
Temperature fault.
The drying temperature is at least 25°F. above the temperature setting. “F5” will flash
on the 4-digit display and the dry cycle will finish without calling for heat (energizing
the gas valve). The power to the dryer must be cycled to reset the controller.
Table 7-7 Dryer Fault Codes
7.7 Accessories
7.7.1 Common Service Parts
Part Numbers
Service Parts
T-30 T-50 T-80
DRIVE BELT,
MOTOR
9040-076-003 9040-076-006 9040-076-011
DRIVE BELT,
TUMBLER
9040-073-009 9040-073-011 9040-073-012
LINT SCREEN
FILTER
9822-026-002 9822-026-001 9822-031-002
Table 7-8 Common Service Parts with Part Numbers
For service and parts information, contact your local Dexter agent. To find your local Dexter
agent, use the Distributor Locator at the website shown below. If a Dexter agent is not
available, contact Dexter Laundry, Inc. directly as listed below:
Mailing Address: 2211 West Grimes Avenue Phone: 1-800-524-2954
Fairfield, IA 52556
USA
Website: www.dexter.com
