20lb C-Series Washer (both voltages 115/208-240)
Resistance
Motor Winding Wire # Minimum Maximum
20lb 1ph or 3ph 60hz Main (wash & spin) T1 & T2 3.91 4.60
Dexter #9376-307-001 T2 & T3 3.91 4.60
Marathon T1 & T3 3.91 4.60
20lb C-Series Express Washer (208-240 only)
Resistance
Motor Winding Wire # Minimum Maximum
60lb 1ph or 3ph 60hz Main (wash & spin) T1 & T2 3.71 4.09
Dexter #9376-307-001 T2 & T3 3.71 4.09
Marathon T1 & T3 3.71 4.09
30lb C-Series Washer
Resistance
Motor Winding Wire # Minimum Maximum
30lb 1ph or 3ph 60hz Main (wash & spin) T1 & T2 2.45 2.71
Dexter #9376-305-001 T2 & T3 2.45 2.71
A.O. Smith #19343600 T1 & T3 2.45 2.71
30lb C-Series Express Washer
Resistance
Motor Winding Wire # Minimum Maximum
60lb 1ph or 3ph 60hz Main (wash & spin) T1 & T2 2.45 2.71
Dexter #9376-305-001 T2 & T3 2.45 2.71
A.O. Smith #19343600 T1 & T3 2.45 2.71
40lb C-Series Washer
Resistance
Motor Winding Wire # Minimum Maximum
40lb 1ph or 3ph 60hz Main (wash & spin) T1 & T2 2.45 2.71
Dexter #9376-305-001 T2 & T3 2.45 2.71
A.O. Smith #19343600 T1 & T3 2.45 2.71
NOTE: Resistance values are measured at the stator. Values at the end of the motor wiring
harness may be slightly higher.
Drive Motor Inverter Type
Motor-Winding Resistance Chart
71
Part # 8533-080-001 12/15
70
Part # 8533-080-001 12/15
Section 5:
Machine Service
Procedures
