- 21 -
Technical data KL-80
Continuous current 80A
Peak current 380A
Resistance 0.0006 ohm
Model 1/8 car
Motor Brushless motor
> 6T
KV < 2400
Batteries
(NiMH or LiPo)
6-12 NiMH cells
2-6 LiPo cells
BEC outlet 5.75V / 3A
Dimensions
(LxWxH)
58mm x 46.5mm x 35mm
(without fan)
Weight 105g (without cables)
4. commissioning thE controllEr
This speed controller is exceptionally efficient. Therefore, put the model in a position
allowing the wheels to turn freely before you turn on the controller!
Connect the controller to the motor, the receiver, the servo and the battery as shown in the
image:
If you are using two batteries, switch them in a row with an
adapter cable (a).
>
a
