Introduction
1
10
I/O Connectors
Expansion Slots
Temperature
Humidity
PCB
• 3 connectors for 6 additional external USB 2.0/1.1 ports
• 2 connectors for external serial ports
• 1 DIO connector
• 1 parallel connector
• 1 front audio connector for line-out and mic-in jacks
• 1 CD-in internal audio connector
• 1 S/PDIF-in/out connector
• 1 connector for IrDA interface
• 6 Serial ATA connectors (BL630-DR)
4 Serial ATA connectors (BL630-D)
• 1 40-pin IDE connector
• 1 floppy connector
• 1 24-pin ATX power connector
• 1 8-pin 12V power connector
• 1 chassis open connector
• 1 front panel connector
• 3 fan connectors
• 1 PCI Express x16 slot
• 1 PCI Express x1 slot
• 4 PCI slots
•0
o
C to 60
o
C
• 10% to 90%
• 4 layers, ATX form factor
• 30.5cm (12") x 24.4cm (9.6")
