1
Introduction
9
Graphics
Audio
LAN
Serial ATA
IDE Interface
Rear Panel I/O
Ports
• Integrated Intel GMA3100
- Up to 384MB maximum video memory
- 2048x1536 at 75 Hz maximum resolution
- Supports DVI port through Serial Digital Video Out (SDVO) in-
terface
- Dual screen display through CRT and DVI-I (DVI-D signal only)
ports
• Realtek ALC885/889 8-channel HD Audio Codec
• High-performance DACs with 106dB dynamic range (A-Weight),
ADCs with 101dB dynamic range (A-Weight)
• Two Realtek PCI Express Gigabit controllers
• Supports 10Mbps, 100Mbps and 1Gbps data transmission
• IEEE 802.3 (10/100Mbps) and IEEE 802.3ab (1Gbps) compliant
• Supports Serial ATA interfaces which are compliant with SATA 1.0
specification
• BL630-DR
- Supports up to 6 SATA devices
- SATA speed up to 3Gb/s
- RAID 0, RAID 1, RAID 0+1 and RAID 5
• BL630-D
- Supports up to 4 SATA devices
- SATA speed up to 3Gb/s
• JMicron JMB368 PCI Express to PATA host controller
• Supports up to 2 UltraDMA 33/66/100Mbps IDE devices
• 1 mini-DIN-6 PS/2 mouse port
• 1 mini-DIN-6 PS/2 keyboard port
• 1 DB-15 VGA port
• 1 DVI-I port (DVI-D signal only)
• 2 RJ45 LAN ports
• 6 USB 2.0/1.1 ports
• 6 audio jacks for center/subwoofer, rear R/L, side R/L, line-in, line-
out (front R/L) and mic-in
