Chapter 3 BIOS Setup www.dfi .comChapter 4 BIOS Setup
45
Chapter 4
Enable or Disable the
Root Port
Aptio Setup Utility - Copyright (C) 2019 American Megatrends, Inc.
Version 2.20.1271. Copyright (C) 2019 American Megatrends, Inc.
PEG Port Confi guration
PEG 0:1:0
Enable Root Port
Max Link Speed
Chipset
 Select Screen
 Select Item
Enter: Select
+/
- :
Change Opt.
F1: General Help
F2: Previous Values
F9: Optimized Defaults
F10: Save & Exit
ESC: Exit
Not Present
[Enabled]
[Auto]
Enable Root Port
Enable or disable the root port.
Max Link Speed
Configure PEF 0:1:0 Max Speed: Auto, Gen1, Gen2 or Gen3.
PEG Port Configuration
This section configures the PEG port.
PCI Express Confi guration
settings
Aptio Setup Utility - Copyright (C) 2019 American Megatrends, Inc.
Version 2.20.1271. Copyright (C) 2019 American Megatrends, Inc.
PCH-IO Confi guration

PCI Express Confi guration

SATA And RST Confi guration

HD Audio Confi guration
LAN(I219)
Wake on LAN Enable
State After G3
Chipset
 Select Screen
 Select Item
Enter: Select
+/
- :
Change Opt.
F1: General Help
F2: Previous Values
F9: Optimized Defaults
F10: Save & Exit
ESC: Exit
[Enabled]
[Enabled]
[S0 State]
PCI Express Configuration
This section configures PCI Express settings.
SATA And RST Configuration
This section configures SATA Device Options settings. Refer next page for more infor-
mation.
HD Audio Configuration
This section configures HD Audio Subsystem settings. Refer page 47 for more informa-
tion.
LAN(I219)
Enable or disable onboard NIC.
Wake on LAN Enable
Enable or disable integrated LAN to wake the system.
State After G3
This field is to specify what state the system should be in when power is re-applied
after a power failure (G3, the mechanical-off, state).
S0 State The system is in working state.
S5 State The system is in soft-off state, except for trickle current to devices such as
the power button.
PCH-IO Configuration
This section illustrates the PCH parameters.
