Chapter 3 BIOS Setup www.dfi .comChapter 4 BIOS Setup
46
Chapter 4
PCI Express Root Port
Settings.
Aptio Setup Utility - Copyright (C) 2019 American Megatrends, Inc.
Version 2.20.1271. Copyright (C) 2019 American Megatrends, Inc.
PCI Express Confi guration

PCI Express Root Port 9

PCI Express Root Port 10

PCI Express Root Port 11

PCI Express Root Port 12

PCI Express Root Port 21

PCI Express Root Port 22

PCI Express Root Port 23

PCI Express Root Port 24
Chipset
 Select Screen
 Select Item
Enter: Select
+/
- :
Change Opt.
F1: General Help
F2: Previous Values
F9: Optimized Defaults
F10: Save & Exit
ESC: Exit
Aptio Setup Utility - Copyright (C) 2019 American Megatrends, Inc.
Version 2.20.1271. Copyright (C) 2019 American Megatrends, Inc.
PCI Express Root Port 9
Hot Plug
PCIe Speed

[Enabled]
[Disabled]
[Auto]
 Select Screen
 Select Item
Enter: Select
+/
- :
Change Opt.
F1: General Help
F2: Previous Values
F9: Optimized Defaults
F10: Save & Exit
ESC: Exit
Control the PCI Express
Root Port.
PCI Express Root Port 9/10/11/12/21/22/23/24
This field is used to enable or disable the PCI express root port.
Hot Plug
Enable or disable the hot plug function of the PCI Express root port.
PCIe Speed
Select the speed of the PCI Express root port: Auto, Gen1, Gen 2 or Gen3.
Chipset
Enable/Disable SATA
Device.
Aptio Setup Utility - Copyright (C) 2019 American Megatrends, Inc.
Version 2.20.1271. Copyright (C) 2019 American Megatrends, Inc.
SATA And RST Confi guration
SATA Controller(s)
SATA Speed
SATA Mode Selection
Serial ATA Port 0
Port 0
Hot Plug
Serial ATA Port 1
Port 1
Hot Plug
Serial ATA Port 4
Port 4
Hot Plug
Serial ATA Port 5
Port 5
Hot Plug
[Enabled]
[Auto]
[AHCI]
Empty
[Enabled]
[Disabled]
Empty
[Enabled]
[Disabled]
Empty
[Enabled]
[Disabled]
Empty
[Enabled]
[Disabled]
 Select Screen
 Select Item
Enter: Select
+/
- :
Change Opt.
F1: General Help
F2: Previous Values
F9: Optimized Defaults
F10: Save & Exit
ESC: Exit
SATA Controller(s)
This field is used to enable or disable the Serial ATA controller.
SATA Speed
Select the SATA speed: Auto, Gen1, Gen 2 or Gen3.
SATA Mode Selection
The mode selection determines how the SATA controller(s) operates.
AHCI
This option allows the Serial ATA controller(s) to use AHCI (Advanced Host Controller
Interface).
Intel RST Premium With Intel Optane System Acceleration (for CH960-
CM246/QM370 only)
This option allows you to create RAID or Intel Rapid Storage configuration with Intel
®
Optane
™
system acceleration on Serial ATA devices. When this mode is selected, “Use
RST Legacy OROM” field will show up for configuration.
Use RST Legacy OROM (for CH960-CM246/QM370 only)
Enable or disable to use RST Legacy OROM when CSM is enabled.
Serial ATA Port 0/1/4/5 and Hot Plug
Enable or disable the Serial ATA port and its hot plug function.
Chipset
