1
Introduction
11
IDE with NVIDIA
RAID
Serial ATA with
RAID
IEEE 1394
Rear Panel I/O
Internal I/O
PCB
• Supports two IDE connectors that allow connecting up to four
UltraDMA 133Mbps hard drives
• NVIDIA RAID allows RAID arrays spanning across Serial ATA
and Parallel ATA
• RAID 0, RAID 1, RAID 0+1 and JBOD
• Four Serial ATA ports
• SATA speed up to 3Gb/s (INFINITY NF SLI-M2/G and INFIN-
ITY NF ULTRAII-M2 only)
SATA speed up to 1.5Gb/s (INFINITY NFII-M2 and INFINITY
NF4XII-M2 only)
• NVIDIA RAID allows RAID arrays spanning across Serial ATA
and Parallel ATA
• RAID 0, RAID 1, RAID 0+1 and JBOD
• VIA VT6307
• Supports two 100/200/400 Mb/sec ports
• 1 mini-DIN-6 PS/2 mouse port
• 1 mini-DIN-6 PS/2 keyboard port
• 1 optical S/PDIF-out
• 1 RCA S/PDIF-out
• 1 parallel port
• 1 COM port
• 1 IEEE 1394 port
• 1 RJ45 LAN port
• 4 USB 2.0/1.1 ports
• Center/subwoofer, rear R/L and side R/L jacks
• Line-in, line-out (front R/L) and mic-in jacks
• 3 connectors for 6 additional external USB 2.0/1.1 ports
• 1 connector for 1 external IEEE 1394 port
• 1 front audio connector for external line-out and mic-in jacks
• 1 CD-in internal audio connector
• 1 S/PDIF connector for optical cable connection
• 1 IrDA connector
• 4 Serial ATA connectors
• 2 IDE connectors
•1 90
o
floppy connector
• 1 24-pin ATX power connector
• 1 4-pin ATX 12V power connector
• 1 4-pin 5V/12V power connector (FDD type)
• 1 front panel connector
• 5 fan connectors
• EZ touch switches (power switch and reset switch)
• ATX form factor
• 24cm (9.45") x 30.5cm (12")
