DFI Infinity NF series - Chapter 1 - Introduction; Specifications

Introduction
1
10
Chapter 1 - Introduction
Specifications
Processor
HyperTransport
Chipset
System Memory
Expansion Slots
SLI (INFINITY NF
SLI-M2/G only)
BIOS
Power Management
Hardware Monitor
Audio
LAN
• AMD
®
Athlon
TM
64 X2 / Athlon 64 FX / Athlon
TM
64 / Sempron
TM
• Socket AM2
• 2000MT/s HyperTransport interface
1600MT/s HyperTransport interface (INFINITY NF4XII-M2 only)
• NVIDIA nForce4
TM
SLI (INFINITY NF SLI-M2/G only)
• NVIDIA nForce4
TM
Ultra (INFINITY NF ULTRAII-M2 only)
• NVIDIA nForce4
TM
(INFINITY NFII-M2 only)
• NVIDIA nForce4-4X
TM
(INFINITY NF4XII-M2 only)
• Four 240-pin DDR2 DIMM sockets
• Supports DDR2 533 and DDR2 667 DIMMs
• Supports dual channel (128-bit wide) memory interface
• Supports up to 4GB system memory
• Supports unbuffered non-ECC x8 and x16 DIMMs
• 2 PCI Express x16 slots
- PCIE1 slot operates at x16 or x8 bandwidth.
- PCIE3 slot operates at x2.
PCIE3 slot operates at x2 or x8 (INFINITY NF SLI-M2/G only).
• 1 PCI Express x1 slot
• 3 PCI slots
• Use identical SLI-ready PCI Express x16 graphics cards
• The bandwidth of each slot is x8; when the graphics cards are
connected via the SLI bridge, it runs at x16 bandwidth.
• Award BIOS
• CPU/DRAM overclocking
• CPU/DRAM/Chipset overvoltage
• 4Mbit flash memory
• ACPI and OS Directed Power Management
• ACPI STR (Suspend to RAM) function
• Wake-On-PS/2 / Wake-On-USB Keyboard/Mouse
• Wake-On-LAN and Wake-On-Ring
• RTC timer to power-on the system
• Monitors CPU/system/chipset temperature
• Monitors 12V/5V/3.3V/Vcore/Vbat/5Vsb/Vdimm/Vchip voltages
• Monitors the speed of the cooling fans
• CPU Overheat Protection function monitors CPU temperature
during system boot-up
• Realtek ALC850 8-channel AC’97 audio CODEC
• True stereo line level outputs
• S/PDIF-in/out interface
• Marvell 88E1115 Gigabit LAN
• Fully compliant to IEEE 802.3 (10BASE-T), 802.3u (100BASE-
TX) and 802.3ab (1000BASE-T) standards
