139
7
SLI Technology
The PCI Express Slots
SLI Mode
The illustration below shows the bandwidth of the PCI Express slots
when in SLI mode.
PCIE 1: x8
PCIE 2: x1
PCIE 3: x8
Normal Mode
The illustration below shows the bandwidth of the PCI Express slots
when in Normal mode.
PCIE 1: x16 or x8
PCIE 2: x1
PCIE 3: x8 or x2
