Hardware Installation
PS/2 Power Select
X
JP7
2-3 On: 5VSB
1-2 On: 5V
(default)
JP7 is used to select the power of the PS/2 keyboard/mouse port.
Selecting 5VSB will allow you to use the PS/2 keyboard or PS/2
mouse to wake up the system.
BIOS Setting
Configure the PS/2 keyboard/mouse wake up function in the Power
Management Setup submenu of the BIOS. Refer to chapter 3 for
more information.
Important:
The 5VSB power source of your power supply must support
≥
720mA.
3
1
2
3
1
2
