Introduction
1
10
Desktop Management Interface (DMI)
The mainboard comes with a DMI 2.0 built into the BIOS. The DMI
utility in the BIOS automatically records various information about
your system configuration and stores these information in the DMI
pool, which is a part of the system board's Plug and Play BIOS.
DMI, along with the appropriately networked software, is designed
to make inventory, maintenance and troubleshooting of computer
systems easier. Refer to chapter 4 for instructions on using the DMI
utility.
Rear Panel I/O Ports (PC 99 color-coded connectors)
• Two USB 2.0/1.1 ports
• One RJ45 LAN port (PM12-TL only)
• One DB-9 serial port
• One DB-15 VGA port
• One DB-25 parallel port
• One mini-DIN-6 PS/2 mouse port
• One mini-DIN-6 PS/2 keyboard port
• One game/MIDI port
• Three audio jacks: line-out, line-in and mic-in
I/O Connectors
• One connector for 2 additional external USB 2.0/1.1 ports
• One connector for 1 external serial port
• One connector for external line-out and mic-in jacks
• Two internal audio connectors (AUX-in and CD-in)
• One connector for IrDA interface
• Two IDE connectors
• One floppy drive interface supports up to two 2.88MB floppy
drives
• Two ATX power supply connectors
• One Wake-On-LAN connector
• One Wake-On-Ring connector
• CPU fan and chassis fan connectors
