2
Hardware Installation
27
The mainboard is equipped with two onboard USB 2.0 (compliant
with USB 1.1) ports (CN1 - Black) located at the ATX double deck
ports of the board.
The system board is also equipped with J13 for connecting 2
additional external USB 2.0/1.1 ports. The USB 2.0/1.1 ports, which
are mounted on a card-edge bracket, will be provided as an option.
If you wish to use the optional USB 2.0/1.1 ports, install the card-
edge bracket to the system chassis then insert the connector that is
attached to the USB 2.0/1.1 port cables to J13. The USB ports’
cable connector can be inserted only if pin 1 of the connector is
aligned with pin 1 of J13. Now connect the interface cable connector
of your USB 2.0/1.1 device to the USB 2.0/1.1 port that is on the
bracket.
You can enable or disable the USB ports in the Integrated Peripher-
als submenu (“OnChip USB Controller” field) of the BIOS.
The Wake-On-USB Keyboard/Mouse function allows you to use a
USB keyboard or USB mouse to wake up a system from the S3
(STR - Suspend To RAM) state.
To use this function:
“USB Resume from S3” (“IRQ/Event Activity Detect” field) in the
Power Management Setup submenu of the BIOS must be set to
Enabled. Refer to chapter 3 for more information.
