Hardware Installation
2.6.3 Universal Serial Bus Ports
Additional USB Ports (USB 3 and USB 4)
CN1
USB 3 and USB 4
(J13)
1
5
11
15
5
15
11
1
USB 2
USB 1
Pin
1
2
3
4
5
Function
VCC
UP5-
UP5+
Ground
Key
Pin
6
7
8
9
10
Function
VCC
UP6-
UP6+
Ground
N. C.
Pin
11
12
13
14
15
Function
Ground
Ground
UP5+
UP5-
VCC
