Diamond Shield Professional
Instruction Manual
Page 17
Running a single program from a sequence
Select the desired sequence with the + and - button. Press the OK
button. The individual programs of this sequence are displayed. Then
select the desired single program.
This program is executed by pressing the START button.
Beforehand the device checks the electrical contact (see "Contact
Control").
During the execution of frequencies
Display
 In the headline the sequence name and the name of the
current single frequency program are shown in turns.
 Below the remaining execution time is displayed
(minutes: seconds).
 Below the intensity is displayed.
◦ For frequency programs with current control the actual
voltage is displayed on the left side. On the right side the
selected intensity is displayed in milliamps (1/1000
amps).
◦ For frequency programs without current control the
actual voltage in volts is displayed.
DS 11
00:07
0.6V 0.30mA
Diamond Shield
00:07
0.6V 0.30mA
