DA435HA: 4-9

DA435HA MOUNTING LOCATIONS

(99903712)

MOUNTING.01: 20050630

DA435HA INSTALLATION ON SERIES 1 AND SERIES 2

DOMINATOR

12.75 12.00

4.40

13.38

0.44 TYP. (4)

DA435HA INSTALLATION ON SERIES 2

DOMINATOR WITH HEADACHE RACK

AND STANDARD HEIGHT SIDEPACK ON

COMPRESSOR SIDE

13.38

12.0018.75

4.40

0.44 TYP. (4)
