DA435HA: 99901219: 1-119980930
1-3. GENERAL INFORMATION
The IMT DA435HA air compressor is a single
stage, air cooled, 4-cylinder, pressure lubricated,
hydraulically driven unit, with a delivery rate of
35 CFM at 100 PSI.
CAUTION
OPERATING THE COMPRESSOR AT PRESSURES
ABOVE 150 PSI WILL SHORTEN THE SERVICE LIFE
AND VOID THE WARRANTY.
1-4. SPECIFICATIONS
Power Source Hydraulic Motor
Bore 2-5/8"
Stroke 2-1/2"
Cylinder Configuration V4
Dimensions 26-1/2"L x 19-1/8"H* x 19-3/4"W
Displacement 44 CFM**
Delivery 35 CFM**
Cooling Air
Fan Diameter 14-1/8"
Operating Speed 1400 RPM maximum
Lubrication Oil Pump
Oil Capacity 1-1/3 qts
Weight 200 lbs.
Reservoir requirement 12 Gallon minimum
Normal GPM @1400rpm 9.3 GPM
Normal Operating PSI 1850 PSI
Maximum PSI 2400 PSI
* Add 2-5/8” to height for air filter cap.
** @ 1400 RPM - 100 PSI
1-1. INTRODUCTION
This manual provides information on the
installation, operation and repair of the IMT Model
DA435HA Hydraulic Air Compressor.
Three means are used throughout this manual to gain
the attention of operating and service personnel.
They are NOTES, CAUTIONS and WARNINGS
and are defined as follows:
NOTE
A NOTE IS USED TO EITHER CONVEY ADDITIONAL
INFORMATION OR TO PROVIDE FURTHER EMPHASIS
FOR A PREVIOUS POINT.
CAUTION
A CAUTION IS USED WHEN THERE IS THE STRONG
POSSIBILITY OF DAMAGE TO THE EQUIPMENT OR
PREMATURE EQUIPMENT FAILURE.
WARNING
A WARNING IS USED WHEN THERE IS THE POTENTIAL
FOR PERSONAL INJURY OR DEATH.
Operate this equipment with respect and service it
regularly for a safer working environment and
longer equipment life.
1-2. ORDERING INFORMATION
When placing orders or requesting assistance, refer
to the information below:
SECTION 1. INTRODUCTION AND SPECIFICATIONS
TO BE COMPLETED BY DEALER
CHASSIS INFORMATION
TRANSMISSION MAKE:
PTO NUMBER:
COMPRESSOR MODEL:
PUMP MAKE:
RESERVOIR CAPACITY:
MODEL:
PTO %:
SERIAL NUMBER:
MODEL:
ENGINE RPM:
COMPRESSOR AND HYDRAULIC PUMP INFORMATION
