OPERATOR’S MANUAL
IntelliAg PDC User 2 & 3
11001-1509A-201105
CONTROL CHANNEL SETUP / 63
TEST GROUND SPEED
Test Ground Speed is the ground speed reference used to perform the test.
ROW
Row is the active row configured in the system. The row that is set here is
the row that reports back a seed count in the Test Seed Count value. The
operator can change the row # to get the seed count of all rows during the
test.
TEST TARGET POP
Test Target Pop is the seed rate at which the test is performed. This value is
the current target rate and is automatically populated.
TEST SEED COUNT
NOTE: Test Seed Count will
automatically reset whenever a
new Continuous Test is
performed.
Test Seed Count is the seed count reported back on a specified row set in
the row data item and is automatically populated.
To Start the Continuous Test:
1. Press the Start button.
2. The test will run for 5 revolutions then stop.
To display the number of seeds detected by each sensor, press the Seed
Count button.
REMOTE TEST SWITCH
A momentary switch can be purchased from DICKEY-john that allows the
the control to be turned on/off during the Continuous and 5 Rev tests.
The switch allows the operator to go back to the implement to perform the
test and investigate mechanical issues or perform seed counts instead of
performing the test inside the cab from the Virtual Terminal. The test switch
will only function when the implement switch is in the up (off) position.
The remote test switch is to be connected to the actuator harness.
Remote test switch part number is 464210515S1.
Once testing is complete, the remote test switch should be
disconnected to prevent accidental control engagement.
