(g.86/C)
(g.87/C)
1
BOOM HEAD LIGHT SWITCH
(OPTIONAL)
(g.86/C Pos.”C”)
Use the relevant switch (fig.86/C Pos.”C”) to turn on the
boom head light (fig.87/C Pos.”1”). The indicator light
switches on to indicate successful activation.
Two work lights, one on the right side and the other on the
left side of the boom, can be installed upon client request.
- ATTENTION
The vehicle can only mount lights supplied by DIECI. Dan-
ger of damage to the electrical system in case of use of non
original lights.
C
