Disengaging the negative parking brake with the
engine stopped
1° Loosen the screws on both sides (g. 167 pos. “1”, “2”)
of the centre part of the front axle with a key (g. 168/C).
Do not completely loosen the screws; loosen them only
enough so that described in point 2 can be carried out.
2° Remove the “U” shaped liners (g. 169/C, Pos.”1”).
3° Re-tighten screws until the click into position in these
conditions it is possible to tow the vehicle.
4° To return the brake to working condition, return in to its
original conditions.
- ATTENTION -
DO NOT USE THE VEHICLE WITH THE HAND BRAKE
DISENGAGED. ONCE TOWING OPERATIONS ARE COM-
PLETE BRING EVERYTHING BACK TO ITS ORIGINAL
POSITION.
- ATTENTION -
It is recommended to have the operations de-
scribed above performed by expert staff.
(g.167/C)
(g.168/C)
(g.169/C)
2
1
