Dieci Agri Farmer - STEERING WHEEL (Adjustment

C/12
Getting to Know and Using the Vehicle
Mod. Agri Farmer
- ATTENTION: - Read the SAFETY REGULATIONS (contained in this manual) carefully for the safety of all personnel and your vehicle.
1
(g.15/C)
(g.16/C)
(g.18/C)
(g.19/C)
(g.17/C)
STEERING WHEEL (adjustment)
(Fig.15/C)
To adjust the steering wheel:
- Turn lever “1” (fig.15/C) downwards to release move-
ments (g.16/C).
- Push the steering wheel forward or pull it back in order
to reach the desired position (g.18/C).
- Push the steering wheel down or pull it up in order to
reach the desired height (g.19/C).
- Turn handle (g.17/C) upwards to lock the steering wheel in
its current position. Screw in with force to lock completely.
- ATTENTION
The steering wheel is correctly adjusted when the operator,
with his/her back resting against the back of the seat, is able
to take hold of the furthest part of the steering wheel with
his/her elbows slightly bent.
