E/7
BASE SYSTEM KEY - DIA. N°25800-053 - (AGRI FARMER EN15K)
NAME DESCRIPTION SHEET
X165 CURRENT SOCKET
4
X167 INTERFACE CONNECTOR L. RIGHT DASHBOARD - L. DRIVER POSITION
1
X172 INTERFACE CONNECTOR L. WINDSCREEN WINDER - L. DRIVER POSITION
10
X175 DIODES INTERFACE CONNECTOR
X176.S CENTRING HANDLER SET-UP CONNECTOR
10
X178.S OPTIONAL POWER SUPPLIES CONNECTOR
7
X184.p CONNECT CONNECTOR WITH X184.s
6
X184.S CONNECT CONNECTOR WITH X184.p
6
X189.S DIAGNOSTICS CONNECTOR
9
X200 INTERFACE CONNECTOR L LEFT DASHBOARD - L DRIVER POSITION
X505 INTERFACE CONNECTOR L MAIN - L DRIVER POSITION
X506 INTERFACE CONNECTOR L. ENGINE - L DRIVER POSITION
X511 INTERFACE CONNECTOR L. ENGINE - L DRIVER POSITION
X517 INTERFACE CONNECTOR L MAIN - L DRIVER POSITION
X525 INTERFACE CONNECTOR L. MAIN - L. DRIVER POSITION
X552 INTERFACE CONNECTOR L. ENGINE - L. DRIVER POSITION
X553 INTERFACE CONNECTOR L. MAIN - L. DRIVER POSITION
X587.p TRAILER SOCKET INTERFACE CONNECTOR
4
X610.S HYDRAULIC JOYSTICK CONNECTOR
6
X611.S JOYSTICK CONNECTOR
6
X635.S OUTRIGGERS SET-UP CONNECTOR
3
X644.S INTERFACE CONNECTOR L. DISTRIBUTOR
9
X648 INTERFACE CONNECTOR L. OUTRIGGERS
9
WirE cOlOurs
A SKY BLUE
B WHITE
C ORANGE
G YELLOW
H GREY
L DARK BLUE
M BROWN
N BLACK
R RED
S PINK
V GREEN
Z PURPLE
nOtE:
WIRES WITH TWO COLOURS ARE INDICATED BY COMBINING THE SYMBOLS ABOVE, FOR EXAMPLE:
G/V - YELLOW/GREEN (HORIZONTAL STRIPES)
Y-G- YELLOW-GREEN (VERTICAL STRIPES)
