F/7
- ATTENTION: - Read the SAFETY REGULATIONS (contained in this manual) carefully for the safety of all personnel and your vehicle.
1. Pump 2. Priority valve 3. Power steering 4. Steering distributor 5. Boom distributor 6. Lifting piston 7. Lock valve 8. Swivel cylinder 9. Compensation cylinder 10. Lock valve 11. Extension cylinder 12. Lock valve 13. Boom head socket 14. Non-return valve 15. Heat exchanger 16. Hydrostatic pump 17. Hydrostatic motor 18. Hydrostatic oil lter 19. Inching valve 20. Negative brake valve 21. Speed change valve 22. Accumulator 23. Non-return valve
HYDRAULIC PLANT KEY
IM03_Agri Farmer vehicle plant with ON_OFF Walvoil-type
A - NEGATIVE BRAKE B - FRONT STEERING C - FRONT BRAKE D - FRONT AXLE E - BACK AXLE G - BRAKES PUMP H - REAR STEERING
