7. When charging is complete, disconnect the charger from the AC power,
disconnect the negative clamp, and nally the positive clamp.
8. A marine (boat) battery must be removed and charged on shore.
BATTERY CHARGING TIMES
BATTERY SIZE/RATING CHARGE TIME
SMALL BATTERIES
Motorcycle, garden tractor, etc.
6-12 Ah 5-10 h
12-32 Ah 10-26.5 h
CARS AND TRUCKS
200-315 CCA 40-60 RC MAINTAIN ONLY
315-550 CCA 60-85 RC MAINTAIN ONLY
550-1000 CCA 85-190 RC MAINTAIN ONLY
MARINE/DEEP-CYCLE
80 RC MAINTAIN ONLY
140 RC MAINTAIN ONLY
160 RC MAINTAIN ONLY
180 RC MAINTAIN ONLY
Times are based on a 50% discharged battery and may change, depending on age
and condition of battery.
AUTOMATIC CHARGING MODE
When an Automatic Charge is performed, the charger switches to the
maintain mode automatically after the battery is charged.
COMPLETION OF CHARGE
When the green LED turns off, the charger has switched to the maintain mode
of operation.
MAINTAIN MODE (FLOAT MODE MONITORING)
When the green LED turns off, the charger has started maintain mode. In
this mode, the charger keeps the battery fully charged by delivering a small
current when necessary.
MAINTAINING A BATTERY
The unit maintains 12 volt batteries, keeping them at full charge.
NOTE: The maintain mode technology allows you to safely charge and
maintain a healthy battery for extended periods of time. However, problems
with the battery, electrical problems in the vehicle, improper connections
or other unanticipated conditions could cause excessive current draws.
As such, occasionally monitoring your battery and the charging process is
recommended.
