DieHard DH150 - Grounding and AC Power Cord; Grounding Requirements; Extension Cord Usage; Assembly and LED Indicator

• 8 •
8. GROUNDING AND AC POWER CORD CONNECTIONS
8.1 This battery charger is for use on a nominal 120 volt circuit. The unit must be
plugged into an outlet that is properly installed and grounded in accordance
with all local codes and ordinances. The plug pins must t the receptacle
(outlet). Do not use with an ungrounded system.
8.2 DANGER: Never alter the AC cord or plug provided – if it does not t the
outlet, have a proper grounded outlet installed by a qualied electrician. An
improper connection can result in a risk of an electric shock or electrocution.
8.3 USING AN EXTENSION CORD
The use of an extension cord is not recommended. If you must use an
extension cord, follow these guidelines:
• Pins on plug of extension cord must be the same number, size, and shape as
those of plug on charger.
• Ensure that the extension cord is properly wired and in good electrical condition.
• Wire size must be large enough for the AC ampere rating of charger, as specied:
Length of cord (feet) 25 50 100 150
AWG* size of cord 18 18 18 16
*AWG-American Wire Gauge
9. ASSEMBLY INSTRUCTIONS
9.1 Remove all cord wraps and uncoil the cables prior to using the battery charger.
10. LED INDICATOR
Pulsing green LED: The charger is connected to AC power.
Solid green LED: The charger is charging the battery.
LED off: The battery is fully charged; the charger is in Maintain Mode.
Solid red LED: Clamps are reversed.
See Operating Instructions for a complete description of the charger modes.
