Operating Manual Program Timers Variotime Single and Variotime Twin
Diehl AKO Stiftung & Co.KG, Appliance Europe, Pfannerstraße 75-83, DE – 88239 Wangen
Tel. +49 (7522) 73-0 • Fax +49 (7522) 73-250 • info@diehl-controls.com • www.diehl.com/controls/appliance
Subject to change without notice – issued 04-2015 – page 18/20
Example:
Variotime is in ON mode, that is, according to the automatic program, the appliance in which the
timer is installed is presently switched on. Pressing the skip button immediately switches the
appliance off, remaining so until the skip button is either pressed again or the next switching
point is reached. This switching point is being executed again according to the automatic program.
Staying with the example, the appliance remains switched off until the next switch on point is
reached.
Vice versa, a switched off appliance is switched on by pressing the skip button . When
reaching the next switching point the skip function is canceled, however, the appliance remains on
as a switch off point is always followed by a switch on point.
Variotime Single
Proceed as follows:
1. Press the skip button once. The appliance changes into the opposite operation mode.
The skip symbol appears in the display, so does the light bulb symbol if the
appliance was off before, or it disappears if the appliance was on before.
Variotime Twin
Proceed as follows:
1. Press the skip button once. The channel indicator 1 flashes and the load connected to
channel 1 is switched.
Press the skip button twice. The channel indicator 2 flashes and the load connected to
channel 2 is switched.
After approximately 3 seconds, the channel indication stops flashing and the skip symbol
appears in the display, so does the light bulb symbol if the load was off before, or it
disappears if the load was on before.
This operation mode continues until the next switching point is reached which will be executed
according to the program. The skip symbol disappears.
2. To cancel the skip function press the skip button again as described above. The skip
symbol disappears and Variotime reverts to the current operation mode according to its
programming.
