Operating Manual Program Timers Variotime Single and Variotime Twin
Diehl AKO Stiftung & Co.KG, Appliance Europe, Pfannerstraße 75-83, DE – 88239 Wangen
Tel. +49 (7522) 73-0 • Fax +49 (7522) 73-250 • info@diehl-controls.com • www.diehl.com/controls/appliance
Subject to change without notice – issued 04-2015 – page 19/20
4 Technical Data
Functions
Time program 7 day program, 24 hour program only optional
Time format 24 hours or 2x 12 hours (am/pm)
Reset function yes
Shortest switching interval 1 minute
Operating modes ON, OFF, Automatic
Product features
Programmable switching
points
16 (8x ON, 8x OFF).
Forming program blocks for days with
the same switching schedule results in a max. of 112
switching points per week (56x ON, 56x OFF)
Display 7 day indicators, 4-digit time display, 2-
activated channel(s), 2-digit indication of the
indication of operation mode and skip function with symbols,
AM/PM indication with 12 hour time format
Operation Via 6 buttons and 2 slide switches with 3 positions each
Quantity of relays 1 (Variotime Single) or 2 (Variotime Twin)
Technical Data
Rated voltage 220-240 V AC, 110-120 V AC, 12 V AC/DC, 24 V AC/DC
Rated frequency 50/60 Hz
Stand by power consumption < 0.5 W
Buffer time
5 minutes
Switch rating Variotime Single with build-in housing: 1x 10 A/250 V AC
Variotime Single with panel-mount housing: 1x 16 A/250 VAC
Variotime Twin: 2x 5(2) A/250 V AC
Max. ambient temperature T55°C
Outer dimensions Variotime with build-in housing: 62 x 62 x 30.5 mm
Variotime with panel-mount housing: 72 x 72 mm
Details see relevant timer drawing
