BEFORE INSTALLING THE CONTROL UNIT, READ THE INSTALLATION
MANUAL AND THE TECHNICAL SPECIFICATIONS CAREFULLY.
THIS MANUAL IS INTENDED FOR TECHNICAL STAFF ADEQUATELY
TRAINED.
The MT200 E control unit, is part of the MT200 family, serves to monitor the
transformer/motor temperatures by means of 3-wire PT100 probes on up to 4
channels.It is equipped with 4 relays, 1 for ventilation, 1 for signalling faults and
2 for PRE-AL and ALARM signals.For connection with supervision systems
(PLC/SCADA) an ETHERNET port is available with MODBUS-TCP
communication protocol, with parameters that can be set via browser.
When one of the temperature probes exceeds the value set by the limits by 1
degree centigrade, the relays and corresponding LEDs switch after about 1
second.
Dimensions
• Container 90X90X115 mm including terminal blocks.
• Front panel 96x96 mm.
• Weight 0.4 Kg.
Power supply
• Universal power supply (24÷240) Volt AC/DC ± 10% 50/60 Hz without
polarity compliance, maximum consumption 4 VA.
