PROGRAM: Enter the control unit programming function.
>>Paragraph PROGRAMMING
ALARMS RESET: It allows alarm reset.
>>Pragraph RESET
RESET DEFAULT: It allows alarms to be reset and factory
settings restored.
>> Paragraph RESET
SET AUTO/MAN/SCAN
Press the button to select the operation between
AUTOMATIC, MANUAL, SCAN.
AUTOMATIC: It displays the highest temperature
found and the corresponding channel number. By
pressing the keys it is possible to read all
the parameters of the control unit:
CH1: channel 1 (probe 1), CH2: channel 2 (probe
2)
CH3: channel 3 (probe 3), CH4: channel 4 (probe
4)
F: program set (see paragraph PROGRAMMING).
If F=4 all the values of each channel are displayed.
P: Pre-alarm, A: Alarm,
L: Fans shutdown, H: Fans running,
(not displayed for configurations 0 and 2)
C: Bearings Protection
Possible alarms activated per channel:
ICF/SCF: probe open or in short-circuit
n: number of times the alarm occurred.
After about two seconds from the last display, the
