32 PM-000251 - Operator’s Manual - PDD-PD50 - June 2022
Type 2,4,6,8
Stowed Travel Position For Skid Steers & Excavators.
Safe operating Range.
Optional Extra - SWING CONTROL SYSTEMS (SCS)
If you have purchased a Swing Control System please ensure you read and understand the following operational procedures.
Drill Head is in Stowed Position, Do Not
Operate in this Position.
Drill Head is Locked. Do not Operate in this
Position, Unit will be damaged.
Left to Right Operating Range.
40°
1
0
0
°
4
5
°
