Below are the layout and schematic drawings of the Speed Controller part number DM-000013 used on 2 Speed
drive units.
HEAT SHRINK
DECAL DE-000131 FOR DM-000013
1500MM
NC12
NC12
NC12
380MM
380MM
70MM
QK2-ASL
WHITE
1
2 BROWN
WIRE ENTRY
1-BLUE
2-WHITE
HEAT SHRINK
70
WIRE ENTRY
QK2-BSL
BROWN
BLUE
DT06-2S
1
2
DM-000013
REMOTE
SUPPLY
DM-000013 - LAYOUT
12 2 Speed Installations-Electrics
2-Speed Controller
