Digi Connect SP User Manual

Specifications and certifications Hardware specifications
Digi Connect Family and ConnectPort TS Family
136
Pin
Number
EIA-232
Signal
01 RI
02 DSR
03 RTS
04 CGND
05 TxD
06 RxD
07 SGND
08 CTS
09 DTR
10 DCD
ConnectPort TS 8 specifications
Specification Value
Environmental Ambient temperature 0 to 60C3 (2 to 140F)
Relative humidity 5 to 95% (non-condensing)
Storage and transport
temperature
-40 to 85C (-40 to 185F)
Altitude 2000 meters (6560 feet)
Serial port protection (ESD) +15 kV human body model
Power
requirements
DC power range 9-30V
Typical power consumption
DC Current @ 120 Vdc (mA)
6W (500mA @ 12Vdc)
Maximum power
consumption
(watts)
12W (1A @ 12Vdc)
Recommended power
supply input rating (watts)
17W (120 VAC @ .14A)
External power supply provided with product
purchase
For units that have a 48VDC DC supply:
13W (48VDC @ .25A)
UL certified Yes
