4.4 Programming of Free Format
M o d e l S M - 5 3 00 O p e r a t i o n M a n u a l | 140
Touch [SAVE] key to store the data. Will
prompt out message “4357 Saving In
Progress”
Note: Touch [MENU] key to exit without
saving the data. A message “Do you
want to save before exit to main menu?”
will appear. Then touch the desired key.
Note 1: Touch [CHARSIZE] key for character size selection.
Touch [X1] key for movement interval selection (X1, X10 & X50) and use [UP], [DOWN], [LEFT]
and [RIGHT] key to move the position of the programmed item data.
Touch [ANGLE] key for angle selection (0, 90, 180 & 270).
Touch [ARROW UP] or [ARROW DOWN] key to move the screen up and down.
Touch Item and drag to change the position.
