Jacks, Buttons, and Ports
Sensor Ports 1,2,3, and 4
• Accepts any RJ12 type sensor made for the Ethernet Gateway.
Power Jack
• The gateway can be powered by connecting a 5V 1A power supply to a North American electrical outlet.
The power jack accepts DC 2.1/6.3mm coaxial power connectors of 12VDC at 1A.
Reset Button
• The reset button is location in a small pinhole on the bottom of the gateway below the device ID label.
Pressing and holding the reboot button for 6 seconds will factory reset the device to its DHCP
conguration.
PC Port
• This connection is only used for initial setup for Static IP using the web GUI of 10.99.99.1 only unless
pre-congured by the manufacturer. Connecting from this port will cause the gateway to act as a DHCP
server and may cause problems on your network.
Internet Port
• This Ethernet port is used for a permanent hardwire connection between your gateway and Internet
router.
For more information about SmartSense visit www.smartsense.co or call 1-866-806-2653
© 1996
-
2018 Digi International Inc. All rights reserved. All other trademarks are the property of their respective owners.
P11
A1/818
