© 2014 Digi International Inc. 90
XBee/XBee-PRO
®
DigiMesh 2.4 User Manual
Antennas approved for use with the XBee RF Modules (Cable loss is shown if required)
Part
Number
Type (Description) Gain Application*
Min.
Separation
Required Cable
Loss
Yagi Class Antennas
A24-Y4NF Yagi (4-element) 6.0 dBi Fixed 2 m
A24-Y6NF Yagi (6-element) 8.8 dBi Fixed 2 m 1.7 dB
A24-Y7NF Yagi (7-element) 9.0 dBi Fixed 2 m 1.9 dB
A24-Y9NF Yagi (9-element) 10.0 dBi Fixed 2 m 2.9 dB
A24-Y10NF Yagi (10-element) 11.0 dBi Fixed 2 m 3.9 dB
A24-Y12NF Yagi (12-element) 12.0 dBi Fixed 2 m 4.9 dB
A24-Y13NF Yagi (13-element) 12.0 dBi Fixed 2 m 4.9 dB
A24-Y15NF Yagi (15-element) 12.5 dBi Fixed 2 m 5.4 dB
A24-Y16NF Yagi (16-element) 13.5 dBi Fixed 2 m 6.4 dB
A24-Y16RM Yagi (16-element, RPSMA connector) 13.5 dBi Fixed 2 m 6.4 dB
A24-Y18NF Yagi (18-element) 15.0 dBi Fixed 2 m 7.9 dB
Omni-Directional Class Antennas
29000430 Integrated PCB Antenna -0.5 dBi Fixed/Mobile 20 cm
A24-F2NF
Omni-directional (Fiberglass base
station)
2.1 dBi Fixed/Mobile 20 cm
A24-F3NF
Omni-directional (Fiberglass base
station)
3.0 dBi Fixed/Mobile 20 cm
A24-F5NF
Omni-directional (Fiberglass base
station)
5.0 dBi Fixed/Mobile 20 cm
A24-F8NF
Omni-directional (Fiberglass base
station)
8.0 dBi Fixed 2 m
A24-F9NF
Omni-directional (Fiberglass base
station)
9.5 dBi Fixed 2 m 0.2 dB
A24-F10NF
Omni-directional (Fiberglass base
station)
10.0 dBi Fixed 2 m 0.7 dB
A24-F12NF
Omni-directional (Fiberglass base
station)
12.0 dBi Fixed 2 m 2.7 dB
A24-F15NF
Omni-directional (Fiberglass base
station)
15.0 dBi Fixed 2 m 5.7 dB
A24-W7NF Omni-directional (Base station) 7.2 dBi Fixed 2 m
A24-M7NF
Omni-directional (Mag-mount base
station)
7.2 dBi Fixed 2 m
Panel Class Antennas
A24-P8SF Flat Panel 8.5 dBi Fixed 2 m 1.5 dB
A24-P8NF Flat Panel 8.5 dBi Fixed 2 m 1.5 dB
A24-P13NF Flat Panel 13.0 dBi Fixed 2 m 6 dB
A24-P14NF Flat Panel 14.0 dBi Fixed 2 m 7 dB
A24-P15NF Flat Panel 15.0 dBi Fixed 2 m 8 dB
A24-P16NF Flat Panel 16.0 dBi Fixed 2 m 9 dB
