Mbox 2 Mini Getting Started Guide32
About Phantom Power
Dynamic microphones (such as a Shure SM57)
do not require phantom power to operate, but
are not harmed by it. Most condenser micro-
phones (like an AKG C3000) do require phan-
tom power to operate.
If you are not sure about the phantom power re-
quirements for your microphone, consult your
microphone’s documentation or contact the
manufacturer.
Input 2 Section
Input 2 Line/DI Input
The Input 2 section includes one Line/DI input.
The Line/DI input accepts line level signals, in-
struments, and other 1/4-inch TRS (Tip-Ring-
Sleeve) or TS (Tip-Sleeve) connections.
On the front panel, the input signal is adjusted
by the Input 2 Gain control.
Pad Switch
The Pad switch engages a –20 dB pad on the in-
put channel 2. When pressed in, the Pad is en-
abled.
Mon Out (Monitor Output)
To monitor your mix, these outputs can be con-
nected to a mixing board, directly to a monitor-
ing system such as a stereo power amp, or an-
other stereo destination.
These outputs accept TRS (Tip-Ring-Sleeve) or TS
(Tip-Sleeve) 1/4-inch connections.
The Mon Out L and R outputs play the audio
that is routed to analog outputs 1 and 2 from
within Pro Tools, respectively. These analog
outputs feature 24-bit digital-to-analog convert-
ers.
USB Port
This standard USB v1.1 connector is used to
connect your computer to the Mbox 2 Mini.
One standard USB cable is included with your
system.
The Mbox 2 Mini is compatible with USB 2.0
ports. However, the USB 2.0 bus will switch to
the slower USB v.1.1 speed to accommodate
Mbox 2 Mini.
Kensington Lock Port
Use the Kensington Lock port to secure your
Mbox 2 Mini with a Kensington Lock (not sup-
plied).
For more information, visit the Kensington web-
site (www.kensington.com).
Although phantom power can be used
safely with most microphones, it is possible
to damage some ribbon microphones with
it. Always turn off phantom power and wait
at least ten seconds before connecting or dis-
connecting a ribbon microphone.
When using phantom power, Mbox 2
Mini’s maximum current per microphone is
4 mA.
