DigiDesign PRE User Manual

Appendix C: MIDI Controller Numbers 43
51h Input Impedance 6 00h=1.5k,
01h=15k,
02h=1.5M
52h Pad 6 00h=out,
7Fh=in
53h Insert 6 00h=out,
7Fh=in
54h 48V 6 00h=off,
7Fh=on
55h Phase 6 00h=off,
7Fh=on
56h High-Pass Filter 6 00h=out,
7Fh=in
57h Mute 6 00h=off,
7Fh=on
59h Input Gain 6 See Table 2
60h Input Source 7 00h=mic,
01h=line,
02h=inst
61h Input Impedance 7 00h=1.5k,
01h=15k,
02h=1.5M
62h Pad 7 00h=out,
7Fh=in
63h Insert 7 00h=ofut
7Fh=in
64h 48V 7 00h=off,
7Fh=on
65h Phase 7 00h=off,
7Fh=on
66h High-Pass Filter 7 00h=out,
7Fh=in
67h Mute 7 00h=off,
7Fh=on
69h Input Gain 7 See Table 2
70h Input Source 8 00h=mic,
01h=line,
02h=inst
Table 1. PRE MIDI Implementation
cc Name PRE
Channel
vv
71h Input Impedance 8 00h=1.5k,
01h=15k,
02h=1.5M
72h Pad 8 00h=out,
7Fh=in
73h Insert 8 00h=out,
7Fh=in
74h 48V 8 00h=off,
7Fh=on
75h Phase 8 00h=off,
7Fh=on
76h High-Pass Filter 8 00h=out,
7Fh=in
77h Mute 8 00h=off,
7Fh=on
79h Input Gain 8 See Table 2
Note that for certain switches, such as the
Mute switches, each “on” message toggles
the state of the switch on or off.
Table 1. PRE MIDI Implementation
cc Name PRE
Channel
vv
