Chapter 1: Introduction to PRE 1
chapter 1
Introduction to PRE
Welcome to the Digidesign
®
PRE™ multi-pur-
pose microphone preamplifier for Pro Tools
®
systems.
PRE is designed especially for use with Pro Tools
systems, but it can also be used as a stand-alone
microphone preamplifier. When used with
Pro Tools, most PRE features can be controlled
from within the Pro Tools application.
With or without remote control, PRE can be
configured manually using its front panel
switches and displays.
PRE can also be remotely-controlled by other
MIDI devices through standard MIDI controller
data. See Appendix C, “MIDI Controller Num-
bers.”
PRE Features
• Eight high-performance, discrete matched
transistor hybrid microphone preamplifica-
tion circuits
• Remote control with qualified Pro Tools TDM
systems and Digidesign control surfaces (such
as D-Control
®
, D-Command
®
, C|24™, Com-
mand|8
®
, Control|24™, and ProControl™)
• Industry-standard DB-25 output connectors
for easy connection to Pro Tools audio inter-
faces or any other recording or mixing me-
dium
• Each channel features:
• Support for microphone (XLR), line level
inputs (1/4-inch), or direct instrument
(1/4-inch)
• Selectable impedance settings for Mic input
• Input gain variable from 0 dB to +69 dB, in
approximately 3 dB steps, with an optional
–18 dB pad
• +48V power for condenser microphones
• Balanced Insert points (Send and Return),
for easy integration of outboard gear (such
as compressors or EQs)
•Phase invert
• 85 Hz High-Pass Filter
• Up to nine PREs supported through software
for up to 72 channels of remote-controlled
preamplification
• All features available in Stand-alone mode
What’s Included
•PRE unit
•AC power cable
•PRE Guide
• Digidesign Registration Information Card
